C 71

ID Tech Solutions offers RFID handheld reader Chainway C 71, is an Android rugged mobile computer. It can be configured with internal UHF module with 1 dBi circularly polarized antenna. With its powerful quad-core processor and wireless connections, you can find this easy-to-deploy device an exceptionally valuable helper to increase working efficiency and productivity in retail, logistics and healthcare.

  • Description

Description

Physical Characteristics of Chainway RFID Handheld Reader C71

Dimensions: 164.2*78.8*17.5mm/6.46*3.10*0.69in

Weight: <321g/11.32oz

Display 5.2” IPS FHD 1920×1080

Touch Panel Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported



Power Main battery: Li-ion, rechargeable, 5000mAh

Standby: over 350 hours

Continuous use: over 12 hours (depending on user environment)

Charging time: 3-4 hours (with standard adaptor and USB cable)



Expansion Slot 1 slot for SIM card, 1 slot for SIM or TF card

Interfaces: USB 2.0 Type-C, OTG

Audio Speaker, 2 microphones

Keypad: 4 front keys, 1 power key, 2 scan keys, 1 multifunctional key

Sensors: Gravity sensor, light sensor, proximity sensor, vibration motor



Performance of  Chainway RFID Handheld Reader C71

CPU: Cortex-A53 Quad-core 1.45GHz

RAM+ROM: 2GB+16GB

Expansion Supports up to 128 GB Micro SD card



Developing Environment for  Chainway RFID Handheld Reader C71

Operating System: Android 6.0

SDK: Chainway Development Kit

Language: Java

Tool: Eclipse / Android Studio



User Environment for  Chainway RFID Handheld Reader C71

Operating Temp.: -4oF to 122oF / -20oC to 50oC

Storage Temp.: -40oF to 158oF / -40oC to 70oC

Humidity: 5%RH – 95%RH non condensing

Drop Specification Multiple 1.8m/5.9ft drops (at least 20 times) to the concrete across the operating temperature range

Tumble Specification 1000 x 0.5m/1.6ft falls at room temperature

Sealing IP65 per IEC sealing specifications

ESD ±15KV air discharge, ±6KV conductive discharge



Communication

WLAN IEEE802.11 a/b/g/n, 2.4G/5G dual-band, internal antenna

WWAN(Europe)

2G:  850/900/1800/1900MHz 3G:  850/900/1900/2100MHz 4G:  B1, B3, B5, B7, B8, B20, B40

WWAN(America)

2G:  850/900/1800/1900MHz 3G:  850/900/1700/1900MHz 4G:  B2, B4, B7, B12, B17

WWAN (China)

2G:  900/1800MHz 3G:  900/1900/2000/2100MHz 4G:  B1, B3, B5, B38, B39, B40, B41

WWAN (Others) Depending on the country’s ISP

Bluetooth Bluetooth 4.0, BLE

GNSS GPS/AGPS, GLONASS, BeiDou; internal antenna





Data Collection

UHF RFID

Frequency 865MHz-868MHz / 920-925MHz / 902-928MHz

Protocol EPC C1 GEN2 / ISO18000-6C

Antenna Circular polarization (1dBi)

Power 1W (27dBm, +19dBm to +30dBm adjustable)

R/W range 1m



Camera

Rear Camera 13MP Autofocus with flash

Front Camera (optional)   5MP camera



NFC

Frequency 13.56MHz

Protocol ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc.

Chips M1 card (S50, S70), CPU card, NFC tags, etc.

Range 2-4cm



Barcode Scanning (optional)

1D Linear Scanner Zebra SE965 / Honeywell N4313

1D Symbologies UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc.

2D Imager Scanner Zebra: SE4710 / SE4750 / SE4750MR; Honeywell: N6603

2D Symbologies PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX), etc.



Iris (optional) Rate <150ms Range 20-40cm FAR 1/10000000 Protocol ISO/IEC 19794-6,GB/T 20979-2007
