UHF 4-PORT READER IDT-404 I
IDT 404 I is an enterprise-class 4-port reader integrated with Impinj R2000 Chip, designed to help enterprises achieve competitive advantage by increasing inventory visibility and process efficiency, resulting in reduced costs and improved profitability. This long-range UHF RFID reader provides flexible connectivity via LAN, USB, Serial & GPIO.
IDT 404 I device reads more than 450 tags per second at distances up to 15 meters (tag and environment dependent) when configured with appropriate antennas. IDT 404 I is an ideal solution for applications including but not limited to Logistics, Access Control, Anti-Counterfeit, Industrial Production, and Process Control systems.
Description
UHF 4-PORT READER IDT-404 I
ID Tech Solutions is a manufacturer, exporter, and provider of a comprehensive range of UHF 4 Port RFID Reader also known as wall-mounted fixed RFID gate readers or UHF RFID gate entrance solutions, which can be used for Gates readers at entry and exit of premises, Library readers, USB readers, Long Range readers, and other customized reading of tags. These RFID readers are used for advanced automation and management system such as Automatic Time Attendance for Schools, Personnel Tracking in Manufacturing Plants, Library Security, Access Control, Toll Plaza Automation, Parking Automation, Hospital Management, Laundry Automation, Event Management, Logistics Management, and other customized automation process and solutions.
The Advantage of using UHF 4 port RFID gate Readers is it saves a lot of time, for access and identification, they are accurate, more reliable can be used in demanding environments, and even in crowded areas, there is no need to flash the card. These RFID readers have an inbuilt motion detector to allow only persons with a valid RFID tag or card to access the premises. These readers are with LF, HF, and UHF frequency, with a reading distance of up to 10 m depending on the RFID reader and environment.
PHYSICAL PARAMETERS
| Dimension | 310mm x 210mm x 41mm |
| Weight | 2 Kg |
| Processor | Impinj R2000 Chip |
| Power Supply | 100-240V AC, DC+9V (Power Adapter) |
| Current Dissipation | 0.5 to 1.2 A |
| Interfaces | RS232, RS485, USB (Host / Slave), GPIO, TCP/IP |
| Indicators | Buzzer & LED (Power, RF, Read, Fault) |
| Housing | Robust Aluminium Body |
ENVIRONMENTAL SPECIFICATION
| Temperature | -25oC to +65oC (Operating), -25oC to +75oC (Storage) |
| Humidity | 5% RH – 95% RH non condensing |
| Protection Class | IP 64 |
UHF RFID
| Work Frequency | Standard ISM 865-867 MHz (IND),865-868 MHz (EU), 902-928 MHz (US) | |||
| Air Interface Protocol | ISO18000-6B, EPC Class 1 Gen2 (ISO18000-6C) | |||
| Read Range | Up to 15m | |||
| Read Rate | 450 Tags/second | |||
| Antenna | 4 TNC Antenna Ports support Antenna Auto-Tuning and Antenna Testing | |||
| Operating Mode | Auto-Running, Interactive and Trigger-Activating | |||
| Max Receiver Sensitivity | -82dBm | |||
| SDP | Provided DLL and Demonstration Software Source code to Facilitate Further Development |
|||
| Power Output | 0-30dBm (adjustable) | |||
| Frequency Hopping | FHSS or Fix Frequency Transmission | |||
ORDER INFORMATION
| Part Number | IDT.UHF.404.I |
