Contact Card Readers – HID OMNIKEY 3021 USB

Contact Card Readers – HID OMNIKEY 3021 USB

Easy to install – Eliminates the need to install drivers; uses native supported CCID drivers within the operating system.
Readily Compliant – Meets all relevant industry standards for smooth integration in PC environment
Portable Form Factor – Unique size makes it an ideal reader for large-scale deployments and mass distribution
Suits Any Application – Compatible with virtually any smart card and major PC operating system
The OMNIKEY® 3021 is a high-performance, USB smart card reader that features all the trusted performance of OMNIKEY readers in
a new and smaller form factor. Compliant with all industry standards, this reader is compatible with virtually any contact smart card, operating system and a variety of applications. This handy USB reader is the ideal choice for
large-scale deployments with any type of contact smart card or application software. The 3021 can be easily distributed together with any smart card, including credit cards,
e-ID cards or software for other  applications.

  • Description

Description

PORTABLE SMART CARD READER
Easy to install – Eliminates the need to install drivers; uses native supported CCID drivers within the operating system.
Readily Compliant – Meets all relevant industry standards for smooth integration in PC environment
Portable Form Factor – Unique size makes it an ideal reader for large-scale deployments and mass distribution
Suits Any Application – Compatible with virtually any smart card and major PC operating system
The OMNIKEY® 3021 is a high-performance, USB smart card reader that features all the trusted performance of OMNIKEY readers in
a new and smaller form factor. Compliant with all industry standards, this reader is compatible with virtually any contact smart card, operating system and a variety of applications. This handy USB reader is the ideal choice for
large-scale deployments with any type of contact smart card or application software. The 3021 can be easily distributed together with any smart card, including credit cards,
e-ID cards or software for other  applications.
FEATURES
Meets major standards, including ISO
7816, EMVCo Terminal 1, Microsoft WHQL, USB CCID, PC / SC and HBCI
(Home Banking Computer  Interface)
Usage within an application is based on standardized interfaces like PC / SC
USB CCID support makes integration
into an existing system the easiest ever by connecting host and smart card reader without the need for additional drivers
Attractive, small size fits in an envelope to distribute with smart card, credit card, e-ID card or software for online banking or digital signature applications
All major operating systems supported
Meets GSA FIPS 201 requirements Supports high-speed data transmission UPC barcode for easier logistics
SPECIFICATIONS

Base Model Number OMNIKEY® 3021
  SMART CARD INTERFACE
Card Size ID-1 (Full size)
Standards ISO 7816
Supported Card Types Class A: 5V @ 60 mA; Class B: 3 V @ 60 mA; Class C: 1.8V @35 mA
Protocols Asynchronous: T=0; T=1 Synchronous: S=8 (I²C) ; S=9 (3-wire); S=10 (2-wire)
Insertion Cycles 100,000
Smart Card Interface Speed 420 kbps
Smart Card Clock Frequency 8 MHz* / up to 12 MHz*


Smart Card detection

Movement detection with auto power-off; Automatic detection of smart card type; Short circuit and thermal protection
8-Pin Handling C4 / C8 supported
  HOST INTERFACE
USB Interface USB 2.0 Full Speed Device (12 MBps)

USB 3.0 extended operability, tested with hubs/controllers**

Connector / Cable USB Type A connector; 59.1″ (150 cm) cable


Operating Systems

Windows 10**/8.1/8/7/Vista/Server 2012**/Server 2008R2 Windows CE (5*/6/7) depending on hardware

Linux Debian 6.0+ / Ubuntu 11.04+/ Fedora 15+; Open SUSE 11.4+ Mac OS X; AndroidTM*

Driver CCID native driver from operating system HID proprietary driver*
Supported APIs PC/SC – API, CT-API* (on top of PC/SC)
  HUMAN INTERFACE
Status indicator Blue LED
  HOUSING
Housing Transparent / grey polycarbonate
Dimensions 2.91″ x 2.52″ x 0.51″ (74 x 64 x 13 mm)
Weight 1.69 oz (48g)
  OPERATING CONDITIONS
Operating Temperature 32-131 F (0-55°C)
Operating Humidity 10-90% rH
Storage Temperature -4 – 176 F (-20 – 80°C)
Meantime Between Failure

(MTBF)

500.000 hours
  COMPLIANCE AND REGULATORY
Compliance / Certification Microsoft WHQL*; EMVCo Terminal Level 1 USB 2.0; TAA*; GSA Fips 201 approved  list*
Regional certifications CE, FCC, UL, VCCI, KCC**, MIC, RCM (C-Tick)
Environmental WEEE, RoHS, Reach
  OPERATING CONDITIONS
Warranty Two-year manufacturer`s warranty
